2019 R nineT Urban G/S
2019 R nineT Urban G/S

2019 R nineT Urban G/S

Description

Eye-catching. Powerful. Air-cooled.

Enjoy the confident feel of a boxer with an upright relaxed riding position, coupled with innovative technology. Choose from countless customizing options for your own unique ideas. The R nineT Urban G/S makes a clear statement: It pays tribute to the early days of BMW Motorrad's G/S success story. Just one look and it's clear that the R nineT Urban G/S captures the off-road spirit of that era. At the same time, its riding characteristics make it a true member of today's nineT family. It reflects the way of life of that time. People knew where they wanted to go, and they knew exactly how they would get there. Same as today..

The source of inspiration: unmistakable.

The design of the R nineT Urban G/S is eye-catching. Distinctive stylistic elements make it a powerful, robust bike that pays tribute to the original G/S design. The 19-inch front wheel, the telescopic fork with the familiar bellows, the headlamp mask with the windscreen and the raised mudguard define the front of the bike. Its profile is defined by a pronounced horizontal line. White body elements and the narrow, slightly longer red seat revive the spirit of the legendary R 80 G/S from 1980. The black engine and frame highlight this effect. The new classic round instruments also show that the Urban G/S is part of the nineT family. The R nineT Urban G/S also excels on everything from unpaved paths to gravel roads. The optional all-terrain tires and spoke wheels, the Enduro foot pegs, the bolted-on heat shield and the steel footbrake lever highlight this fact, both functionally and visually.

Technology for pure riding fun.

The R nineT Urban G/S is faithful to the past with its looks but it shows equal respect for the present with its modern technology. It features the proven engine and electrical system of the BMW R nineT. The R nineT Urban G/S also meets the current EU-4 standard thanks to its state-of-the-art technology. The powerful air-cooled, two-cylinder boxer engine features a capacity of 1,170 ccm and 81 kW (110 bhp) of output for a highly dynamic power delivery, even at low speeds. The standard ABS and optional ASC Automatic Stability Control ensure that you're always safe when you bring your power to the road – or gravel.

Upright and commanding.

The balanced ergonomic triangle of the Urban G/S keeps you agile and confident on the road. The slightly higher handlebar, the long seat surface and slightly deeper and wider rear mounted footrests make for a more relaxed and confident riding experience. The standard seat height of the series is 850 mm. Thanks to an optional lower seat of 820 mm, the R nineT Urban G/S offers stability for riders of almost all sizes.

Features may include:

  • Distinctive front.

Headlamp mask, round headlights with windscreen: a front reminiscent of vintage G/S bikes.

  • Front mudguard.

Dirt doesn't stand a chance: the raised mudguard keeps things rolling. Nothing gets clogged with mud and dirt.

  • A perfect colour scheme.

White tank, blue accents and the red seat: classic BMW M.

  • Enduro foot pegs.

For better hold and better vehicle control for offroad use and driving while standing.

  • Large 19-inch front wheel.

The 19-inch front wheel with optional all-terrain tires brings up memories of rides on almost impassable terrain.

  • Red seat.

The inspiration is clear: just like the R 80 G/S, the R nineT Urban G/S also has the distinctive long red seat.

  • White indicators.

Elegant and modern: White indicators.

  • Bolted-on heat shield.

A classic enduro touch: heat shield on the brushed stainless steel rear silencer.

Specifications

  • ENGINE
    add remove
    • Type
      Air/oil-cooled flat twin ('Boxer') 4-stroke engine, two camshafts and four radially aligned valves per cylinder, central counterbalancer shaft
    • Bore / stroke
      101 mm x 73 mm
    • Capacity
      1,170 cc
    • Nominal load capacity
      81 kW / 7,750 rpm
    • Max. torque
      116 Nm at 6,000 rpm
    • Compression ratio
      12.0:1
    • Emission control
      Controlled 3-way catalytic converter, exhaust emission standards EU-4
    • Fuel/engine management
      Electronic intake pipe fuel injection, electronic engine management with overrun cut-off, twin-spark ignition
  • PERFORMANCE / FUEL CONSUMPTION
    add remove
    • Maximum speed
      Over 200 km/h
    • Fuel consumption per 100 km based on WMTC
      5.3 l
    • CO2 emission based on WMTC
      123 g/km
    • Fuel type
      Unleaded petrol, 95-98 octane (RON) (nominal load capacity with 98 octane (RON))
  • POWER TRANSMISSION
    add remove
    • Clutch
      Hydraulically operated single-disc dry clutch
    • Gearbox
      Constant mesh 6-speed gearbox with helical gear teeth
    • Drive
      Shaft drive
  • CHASSIS / SUSPENSION / BRAKES
    add remove
    • Frame
      three-part frame concept with front frame and two-part rear frame, load-bearing engine-gearbox unit, rear-set frame removeable for one-up riding
    • Rear suspension / spring elements
      Cast aluminium single swing-arm with BMW Motorrad Paralever; central spring strut, spring preload via hook wrench can be adjusted infinitely, rebound stage damping adjustable
    • Spring travel, front/rear
      125 mm / 140 mm
    • Front wheel location / suspension
      Telescopic forks, 43 mm fixed-tube diameter
    • Wheelbase
      1,527 mm
    • Castor
      110.6
    • Steering head angle
      61.5 °
    • Wheels
      Spoke cast wheels
    • Rim, front
      3.00 x 19
    • Rim, rear
      4.50 x 17
    • Tyre, front
      120/70 ZR 19
    • Tyre, rear
      170/60 ZR 17
    • Brake, front
      Twin disc brake, diameter 320 mm, 4-piston fixed calipers
    • Brake, rear
      Single disc brake, diameter 265 mm, double-piston floating caliper
    • ABS
      BMW Motorrad ABS
  • DIMENSIONS / WEIGHTS
    add remove
    • Rider step length, unladen
      1,890 mm
    • Usable tank volume
      4.5 gal
    • Reserve
      approx. 3.5 l
    • Unladen weight, road ready, fully fuelled
      221 kg
    • Max. permitted weight
      948 lbs
    • Max. load (with standard equipment)
      209 kg
    • Length
      2,175 mm
    • Seat height, unladen
      850 mm
    • Height (including mirrors)
      1,330 mm
    • Width (including suitcase)
      870 mm
  • Color options
    add remove
    • Light White
